ITV500 Mini HeatVision

ITV500 thermal camera – See the heat before anything burns out

Heat is always the first warning – long before anything breaks. Motors, ESCs, LiPo batteries and connectors slowly get too hot, magnets lose strength, MOSFETs go into thermal runaway, and batteries age and swell. With the ITV500 you get a compact, precise thermal camera that makes invisible heat visible, so you can protect your RC setup and fine-tune performance down to a few degrees.

Features and benefits
The ITV500 is developed for serious RC tuning, where every degree counts – both for performance and lifespan.

• Reveals critical hotspots on motor, ESC, LiPo, connectors and wires
• Helps optimize gearing, timing and cooling via direct temperature feedback
• Prevents hidden damage such as demagnetization, thermal runaway and battery swelling
• Contactless measurement – no touching hot or rotating parts
• Pocket-sized and only approx. 38 g – always ready in the pits or in your pocket

How the ITV500 sees heat
All surfaces emit invisible heat (FIR – far infrared). The ITV500 detects this energy and converts it into precise, contactless temperature data, which is displayed as a live thermal image on the screen. You instantly see what is hot, and where it becomes dangerous.

• Live thermal image of your entire RC setup
• Accuracy up to ± 2 °C, so you always know what is running hot
• Ideal for both quick pit checks and detailed troubleshooting
• Note: Long measuring distances can show lower temperatures due to physical limitations in IR measurement – move closer (within 20 cm) for the most accurate results

Adjustable emissivity – accurate on all RC materials
From metal motors to carbon chassis: the ITV500’s adjustable emissivity from 0.01–1.00 ensures that you can calibrate the measurement to almost any surface.

• Provides more realistic temperatures on different materials
• Reduces “material bias”, so you can compare hotspots more reliably
• Emissivity is set directly on the device for optimal accuracy

Note: Emissivity depends on material, surface roughness and oxidation and may deviate from reference values. The higher the emissivity, the more accurate the measurement. For low-emissivity surfaces such as shiny metals or glass, it is recommended to use black tape or black paint on the measuring point for better accuracy.Smart visualization and operation
The ITV500 is designed for quick use in the pits, so you can react immediately.

• Choose between color palettes: Rainbow, Iron Red (Ironbow) or White Hot
• Tap the screen to measure any point directly in the image
• Automatic marking of the hottest and coldest point in the image
• Switch between °C / °F / K as needed
• Adjust brightness, fine-tune emissivity and customize other settings directly on the touchscreen
• Six-language interface: EN / 中文 / FR / DE / ES / JP
• Auto power-off function to save battery

Compact, pit-ready and always up to date
With its low weight and compact size, the ITV500 is built to be a permanent tool in your RC bag.

• Only approx. 38 g – takes up minimal space in pocket or pit bag
• 1.83" bright, capacitive touchscreen with 240 × 284 pixels
• USB-C charging – quick and simple
• Firmware update via UF2 drag-and-drop – no tools, no hassle

Specifications

• Size: 46 × 38 × 20.1 mm
• Weight: approx. 38 g
• Display type: 1.83" capacitive touchscreen
• LCD display resolution: 240 × 284 pixels
• IR resolution: 32 × 24 pixels
• Thermal sensitivity: 100 mK @ 1 Hz
• Field of view (FOV): 55° × 35°
• Frame rate: 8 FPS
• Battery (built-in): 600 mAh rechargeable lithium battery
• Charging interface: USB Type-C
• Charging input voltage: DC 5 V
• Temperature measurement range: -20 °C (-4 ℉) ~ 300 °C (572 ℉)
• Measurement accuracy: ± 2.0 °C (3.6 ℉)
• Measuring distance: < 5 m (for high accuracy, within < 20 cm)
• Languages: EN / CN / FR / DE / ES / JP
• Operating temperature: -5 °C – 60 °C
• Operating humidity: ≤ 85% RH, non-condensing
• Storage temperature: 0 °C – 35 °C
• Storage humidity: ≤ 65% RH, non-condensing

The ITV500 gives you full insight into the heat across your entire RC setup, so you can run harder, faster and safer – without guessing temperatures.
